2BV Series Liquid Ring Vacuum Pump

2BV Series Liquid Ring Vacuum Pump

2BV Series Liquid Ring Vacuum Pump Introduction:

2BV Series Liquid Ring Vacuum Pump

  • 2BV series liquid ring vacuum pump manufactured by Denair, including 2BV5、2BV2 and 2BV6 series, exceeding the industry requirement with exceptional performance, are mainly used for suction in pharmacy, plastic machine, chemical, oil&gas, marshgas and other industry.
  • Denair 2BV series liquid ring vacuum pump has compact structure, the rators of 2BV2 and 2BV5 are mounted directly on the motor shaft, no connector involved. The pump case is installation directly on the motor case, no need centering.The bronze impeller from standard configuration improves the corrosion resistance of vacuum pump. The mechanical seal from standard configuration eliminates the leakage and reduces maintenance. Patterned flexible vent ensures a perfect operation status. 2BV6, made of stainless steel is more capable of working in harsher environment.

Consistently high efficient operation:

  • In a circumstance of limited installation space, compact design undoubted is one of its advantages, 30% smaller than normal China-made liquid ring vacuum pump.
  • With advantage of low noise, no need to equip a muffler, realizing compact design and low cost.
  • Low liquid consumption, equipping water separator to recycle 50 % operating liquid could further reduce operation cost.
  • Closed-loop system limits the production of drain water, reduces the supply of supplement liquid. The condensate generated in transferred media can be used after being recycled.

Abundant experience:

  • Acting as supplement of standard pump or single electric motor, complete 2BV set can be supplied including water separator, heat exchanger and cavitation protection connecting pipeline, what’s more, the liquid ring vacuum pump can be combined with other vacuum pump system like roots vacuum pump. Based on Denair’s strong advantage in vacuum pump, electric motor and electrical control, we could provide complete solution for customers.

Free maintenance:

  • 2BV vacuum pump requires no maintenance because of its unique 100% oil free design, no need to replace oil filtering equipment. Add lubricant grease every five years in normal using condition. The mechanical seal, unlike packing seal, requests no periodical adjustment.
Features Advantages
Coaxial pump and direct connect design Easy installation, compact design, easy maintenance.
Bronze or stainless steel impeller Enhanced corrosion resistant performance
100% oil free Environmental friendly
Unique flexible vent design Optimum working efficiency
Adopt mechanical seal as standard configuration Leakage proof, cut down maintenance cost
Smooth and reliable operation, low noise. No muffler
Low liquid consumption Reduce operating cost
Only one rotating part No abrasion, long-life time, free maintenance.
with the function of self-absorption Easy operation
Over 100 years experience in design vacuum pump and air compressor Excellent quality and performance
Curve No. Product code Maximum suction capacity
(m³/min)
Motor power
(kW)
Ultimate vacuum
(mbar)
Speed
(r.p.m)
Operating liquid flow rate
(L/min)
Noise
db(A)
Weight
Kg
60V 2BV2-060 0.45 0.81 33mbar
(3300pa)
2840 2 62 37
61V 2BV2-061 0.86 1.45 2840 2 65 41
70V 2BV2-070 1.33 2.35 2860 2.5 66 66
71V 2BV2-071 1.83 3.85 2880 4.2 72 85
110V 2BV5-110 2.75 4 1440 6.7 63 120
111V 2BV5-111 3.83 5.5 1440 8.3 68 150
121V 2BV5-121 4.66 7.5 1440 10 69 210
131V 2BV5-131 6.66 11 1460 15 73 280
161V 2BV5-161 8.33 15 970 20 74 390
110V 2BV6-110 2.75 4 1440 6.7 63 148
111V 2BV6-111 3.83 5.5 1440 8.3 68 196
121V 2BV6-121 4.66 7.5 1440 10 69 220
131V 2BV6-131 6.66 11 1460 15 73 314
161V 2BV6-161 8.33 15 970 20 74 426

*) Specifications are subject to change without prior notice
