Oil-free Scroll Air Compressor

Oil-free Scroll Air Compressor

Oil-free Scroll Air Compressor Advantages:


  • Clean Air 100% Oil-Free
    Oil-free type compressors can supply clean air.
  • Low noise & Low Vibration
    Silent operation and low vibration assure comfortable and quiet work space.
  • Safe Backup Function
    Even if one air end fails, another air end automatically replaces it by jump control. Unmanned operation at night has become easy.
  • Easy to Control
    High quality microcomputer is mounted. Digital maintenance monitor displays operating conditions, warnings and cautions. Automatic power failures and reset function can be dealt with easily.
  • Compact and Smart Design
    There are no extruding handles on the back of machine. Its simple design and reduced installation space required allow it to fit well in any office.
  • Designed especially for medical, pharmacy, laboratory, instrument, coating, chemical industry and food processing, etc.
Oil-free Scroll Air Compressor Technical Parameters:
Type Maximum working pressure Capacity(FAD) installed motor power No of air end Outlet Diameter Noise Level** Dimensions (mm) Weight
50 Hz 60 Hz
bar(e) psig m³/min cfm m³/min cfm kW hp Units inch dB(A) L W H kg
DWW-2 7.5 109 0.24 8 0.24 8 2.2 3 1 G1/2" 65 920 720 940 230
8.5 123 0.23 8 0.23 8 2.2 3 G1/2" 65 920 720 940 230
10.5 152 0.21 7 0.21 7 2.2 3 G1/2" 65 920 720 940 230
DWW-3 7.5 109 0.43 15 0.42 15 3.7 5 1 G1/2" 65 920 720 940 230
8.5 123 0.40 14 0.40 14 3.7 5 G1/2" 65 920 720 940 230
10.5 152 0.37 13 0.37 13 3.7 5 G1/2" 65 920 720 940 230
DWW-5 7.5 109 0.60 21 0.60 21 5.5 7.5 2 G1" 68 1150 760 1020 360
8.5 123 0.58 20 0.57 20 5.5 7.5 G1" 68 1150 760 1020 360
10.5 152 0.53 19 0.53 19 5.5 7.5 G1" 68 1150 760 1020 360
DWW-7 7.5 109 0.86 31 0.84 31 7.5 10 2 G1" 68 1150 760 1020 360
8.5 123 0.80 28 0.80 28 7.5 10 G1" 68 1150 760 1020 360
10.5 152 0.74 26 0.73 26 7.5 10 G1" 68 1150 760 1020 360
DWW-11 7.5 109 1.26 45 1.26 45 11 15 3 G1" 70 1150 760 1400 500
8.5 123 1.20 43 1.20 43 11 15 G1" 70 1150 760 1400 500
10.5 152 1.10 39 1.10 39 11 15 G1" 70 1150 760 1400 500
DWW-15 7.5 109 1.72 61 1.72 61 15 20 4 G1/2" 70 1800 1300 1440 720
8.5 123 1.64 58 1.64 58 15 20 G1/2" 70 1800 1300 1440 720
10.5 152 1.51 53 1.51 53 15 20 G1/2" 70 1800 1300 1440 720
DWW-18 7.5 109 2.07 73 2.07 73 18 25 5 G1/2" 72 1800 1300 1440 860
8.5 123 1.97 70 1.97 70 18 25 G1/2" 72 1800 1300 1440 860
10.5 152 1.81 64 1.81 64 18 25 G1/2" 72 1800 1300 1440 860
DWW-22 7.5 109 2.53 89 2.53 89 22 30 6 G1/2" 72 1800 1300 1440 900
8.5 123 2.41 85 2.41 85 22 30 G1/2" 72 1800 1300 1440 900
10.5 152 2.21 78 2.21 78 22 30 G1/2" 72 1800 1300 1440 900
DWW-30 7.5 109 3.44 121 3.44 121 30 40 8 G1/2" 75 1800 1300 1820 1200
8.5 123 3.28 116 3.28 116 30 40 G1/2" 75 1800 1300 1820 1200
10.5 152 3.01 106 3.01 106 30 40 G1/2" 75 1800 1300 1820 1200
DWW-37 7.5 109 4.25 150 4.25 150 37 50 9 G1/2" 75 1800 1300 2200 1420
8.5 123 4.05 143 4.05 143 37 50 G1/2" 75 1800 1300 2200 1420
10.5 152 3.72 131 3.72 131 37 50 G1/2" 75 1800 1300 2200 1420

*) FAD in accordance with ISO 1217:2009, Annex C: Ansolute intake pressure 1 bar (a), cooling and air intake temperature 20℃
**) Nosie level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance:±3 dB(A)

Specifications are subject to change without prior notice

Type Maximum working pressure Capacity(FAD) installed motor power No of air end Outlet Diameter Noise Level** Dimensions (mm) Weight
50 Hz 60 Hz
bar(e) psig m³/min cfm m³/min cfm kW hp Units inch dB(A) L W H kg
DWW-2 7.5 109 0.24 8 0.24 8 2.2 3 1 G1/2" 65 920 720 940 230
8.5 123 0.23 8 0.23 8 2.2 3 G1/2" 65 920 720 940 230
10.5 152 0.21 7 0.21 7 2.2 3 G1/2" 65 920 720 940 230
DWW-3 7.5 109 0.43 15 0.42 15 3.7 5 1 G1/2" 65 920 720 940 230
8.5 123 0.40 14 0.40 14 3.7 5 G1/2" 65 920 720 940 230
10.5 152 0.37 13 0.37 13 3.7 5 G1/2" 65 920 720 940 230
DWW-5 7.5 109 0.60 21 0.60 21 5.5 7.5 2 G1" 68 1150 760 1020 360
8.5 123 0.58 20 0.57 20 5.5 7.5 G1" 68 1150 760 1020 360
10.5 152 0.53 19 0.53 19 5.5 7.5 G1" 68 1150 760 1020 360
DWW-7 7.5 109 0.86 31 0.84 31 7.5 10 2 G1" 68 1150 760 1020 360
8.5 123 0.80 28 0.80 28 7.5 10 G1" 68 1150 760 1020 360
10.5 152 0.74 26 0.73 26 7.5 10 G1" 68 1150 760 1020 360
DWW-11 7.5 109 1.26 45 1.26 45 11 15 3 G1" 70 1150 760 1400 500
8.5 123 1.20 43 1.20 43 11 15 G1" 70 1150 760 1400 500
10.5 152 1.10 39 1.10 39 11 15 G1" 70 1150 760 1400 500
DWW-15 7.5 109 1.72 61 1.72 61 15 20 4 G1/2" 70 1800 1300 1440 720
8.5 123 1.64 58 1.64 58 15 20 G1/2" 70 1800 1300 1440 720
10.5 152 1.51 53 1.51 53 15 20 G1/2" 70 1800 1300 1440 720
DWW-18 7.5 109 2.07 73 2.07 73 18 25 5 G1/2" 72 1800 1300 1440 860
8.5 123 1.97 70 1.97 70 18 25 G1/2" 72 1800 1300 1440 860
10.5 152 1.81 64 1.81 64 18 25 G1/2" 72 1800 1300 1440 860
DWW-22 7.5 109 2.53 89 2.53 89 22 30 6 G1/2" 72 1800 1300 1440 900
8.5 123 2.41 85 2.41 85 22 30 G1/2" 72 1800 1300 1440 900
10.5 152 2.21 78 2.21 78 22 30 G1/2" 72 1800 1300 1440 900
DWW-30 7.5 109 3.44 121 3.44 121 30 40 8 G1/2" 75 1800 1300 1820 1200
8.5 123 3.28 116 3.28 116 30 40 G1/2" 75 1800 1300 1820 1200
10.5 152 3.01 106 3.01 106 30 40 G1/2" 75 1800 1300 1820 1200
DWW-37 7.5 109 4.25 150 4.25 150 37 50 9 G1/2" 75 1800 1300 2200 1420
8.5 123 4.05 143 4.05 143 37 50 G1/2" 75 1800 1300 2200 1420
10.5 152 3.72 131 3.72 131 37 50 G1/2" 75 1800 1300 2200 1420

*) FAD in accordance with ISO 1217:2009, Annex C: Ansolute intake pressure 1 bar (a), cooling and air intake temperature 20℃
**) Nosie level as per ISO 2151 and the basic standard ISO 9614-2, operation at maximum operating pressure and maximum speed; tolerance:±3 dB(A)

Specifications are subject to change without prior notice
